Description
The Broil King Regal Q 690 Pro IR Propane Gas Grill is designed for grillers who want exceptional power, control, and versatility. Featuring iQue smart grill technology, it allows you to manage temperatures and monitor your cook from your phone, offering convenience and precision in one system. Its large 70-inch frame houses two separate cook boxes, providing a total of 1,030 square inches of cooking space, including 750 and 250 square inches of primary grilling area.
This grill includes six stainless steel Dual-Tube burners delivering 60,000 BTUs of heat, a 10,000 BTU infrared side burner for searing, and a 15,000 BTU rear rotisserie burner with a premium rotisserie kit. The cooking surface features a mix of solid 9mm stainless steel rods and heavy-duty cast iron grids, supported by the Flav-R-Wave cooking system for even heat distribution and enhanced flavor.
Built for durability, the Regal Q 690 Pro IR comes with a stainless steel hood and cook box with cast aluminum end caps, pull-out LP tank drawer, built-in control panel lights, and heavy-duty locking casters. From dual temperature zones to advanced ignition and lighting, this grill is built to elevate your outdoor cooking experience.
Features:
System
- 60,000 BTU stainless steel Dual-Tube™ burner system
- 10,000 BTU Infrared side burner
- 15,000 BTU stainless steel rear rotisserie burner
- Premium rotisserie kit included
- 1,030 sq. in. total cooking space including porcelain-coated warming rack
- 750 sq. in. / 3,225 sq. cm. primary large cook box
- 250 sq. in. / 1,613 sq. cm. primary small cook box
- Two completely separate cook boxes
- Large cook box: Solid 9 mm stainless steel rod grids
- Small cook box: Heavy-duty cast iron cooking grids
- Infrared side burner: 8 mm stainless steel rod grids
- Six stainless steel Dual-Tube™ burners
- Stainless steel Flav-R-Wave™ cooking system
- Linear-Flow™ valves with 180° sensi-touch™ control
- Sure-lite™ electronic ignition system
- Two Deluxe Accu-Temp™ thermometers
Design
- Stainless steel hood panel and cook box with cast aluminum end caps
- Stainless steel control panel and side shelves with cast aluminum condiment bins
- Enclosed black cabinet base with stainless steel cabinet doors
- Heavy-duty locking, swivel casters with level setting
- COB handle-mount grill light included
- Propane models have a pull-out tank drawer for easy changes
- Built-in control panel lights
Fuel Options
- Natural Gas (NG) - 10ft natural gas hose included.
- Propane (LP) - designed for use with 20lb tank - not included.
Specifications:
| Item Number | BK689244 |
| Model | Q Regal 690 Pro IR |
| Fuel Type | Liquid Propane |
| No. of Burners | 6 |
| Main Burner Output | 60,000 BTU |
| Infrared Burner | 10,000 BTU |
| Rotisserie Burner | 15,000 BTU |
| Primary Cooking Space | 750 SQ. IN. |
| Dimensions | 49.2" (H) x 70" (W) x 24.8" (D) |
| Weight | 270 lbs. |
Warranty:
 |
We reward quality. This Broil King® features a Limited Lifetime Warranty on the entire cookbox, 15 years on Dual-Tube™ burner system, and 15 years top to bottom, on all remaining parts and paint. |
Documents & Files:
About The Manufacturer :
We proudly manufacture our gas grills in our own North American factories using carefully designed domestic and global components. By embracing continuous improvement and adhering to strict international quality standards, our team is dedicated to providing premium products.
