EcoSmart Fire 18" Flex 18BY Bay Ethanol Fireplace Insert with Glass Windscreen by Mad Design Group

The EcoSmart Fire 18" Flex 18BY Bay Ethanol Fireplace Insert offers a stylish 3-sided flame view, perfect for indoor or outdoor installations. Its compact design provides both ambiance and warmth without the need for gas, electricity, or venting.

Constructed from durable mild steel and toughened glass, this fireplace insert requires minimal maintenance while ensuring long-lasting performance. The included glass windscreen enhances safety and protects the flame from outdoor wind, making it a practical choice for patios and indoor spaces alike.

Bay Ethanol Fireplace Inserts are available in other sizes and configuration i.e. 32BY, 42BY, 50BY, 50BY with Decorative Box, 60BY with Decorative Box, 68BY, 68BY with Decorative Box, 78BY with Decorative Box, 86BY, 86BY with Decorative Box, 104BY, 104BY with Decorative Box, 122BY, 122BY with Decorative Box, 140BY with Decorative Box, 158BY, 158BY with Decorative Box

FUEL EFFICIENCY:

Volume Capacity	0.7 Gal [2.5 L]
Heats on Average	215ft2 [20m2]
Minimal Room	1413ft3 [40m3]
Thermal Output	6.1 MJ/h - 5800 BTU/h - 1.7 kW
Burn Time	8 - 11h

*Please Note: "These values are indicative only and may vary depending on the model purchased, installation environment, and the composition of the e-NRG bioethanol sourced in each country."

What's Included:

Fireplace Insert, Glass Windscreen, Black Glass Charcoal, Bioethanol Burner, 1.25 Gallon Jerry Can, Bottle Adapter, Refillable Butane Fire Lighter and Lighting Rod

*Note: "e-NRG Bioethanol Fuel for the burner is sold separately. Glass windscreen included. Black Fireboxes come with Stainless Steel Burners. Model comes with Black Glass Charcoal."

KEY FEATURES:

Application

Indoor or outdoor single room application. With one open side, view the flame from the front.

Colors

Available in black, firebox comes with stainless steel burners and decorative Black Glass Charcoal.

No Gas or Electricity

No gas, no electricity, no chimney, no venting or external vent cap. 4 fewer General Contractors.

Clean Burning

All the fuel is housed within Flex’s self-contained burner so you don’t have to run a gas line or electric wires through your walls. And because e-NRG Bioethanol is clean burning, you don’t need a flue or a chimney

Zero Clearance

Self-contained, zero clearance construction allows your Flex fireplace to be framed into wood or metal studs, providing installation freedom and flexibility for builders.

Quick and Easy Assembly

Requiring virtually no assembly, Flex Fireboxes are designed to be placed into the desired location, safely secured into position, and operated immediately.

Rust Proof

Zinc sealed steel construction powder coated with super hi-temp black paint prevents rusting so all fireplaces can be used both indoors or outdoors.

Luxurious Finish

Available in a timeless black finish, Flex Fireboxes come with stainless steel burners and black glass charcoal.

Wind Screen

Included integrated windscreen sits flush behind frame.

Tested World Wide

EcoSmart collection has been thoroughly tested against a number of global standards and are UL Listed in the USA, Certified for EU and UK in accordance with EN16647, and satisfy the ACCC Safety Mandate for Australia.

STANDARD FEATURES:

• Built-in 3-Sided Ethanol Firebox for Indoor or Outdoor Installation
• Easy or no Maintenance Required.
• Made of Mild Steel and Toughened Glass
• No Gas, Electricity, Chimney, or Venting Required

• Adjustable Flame - allows you to control the flame intensity and heat output.
• Safe Filling - safer than most other ethanol fireplaces.
• Glass Windscreen Included - for safety and wind protection.
• ISO Certified

• UL Listed

Dimensions	18.1" W x 14.4" D x 31.8" H
Weight	89.73lb [40.70kg]
Warranty	Stainless steel parts including raw, linished and powder coated: 2 Years from Date of Purchase Mild steel including powder coated and chrome plated, Cement, Glass, Leather, Fabric and MDF (Painted OR Cement Rendered): 1 Year from Date of Purchase
