Description
Introducing the Enervex RS16 Chimney Fans with Horizontal Discharge – the pinnacle of chimney performance solutions. If you've ever experienced frustrating draft issues or concerns about smoke entering your living space, it's time to take control of your chimney's performance.
The Enervex RS16 Chimney Fan is engineered to revolutionize the way your chimney operates, ensuring a consistent and efficient draft. Say farewell to draft-related problems and the inconvenience of smoky interiors. This fan offers the assurance of smoke-free living and significantly enhances the safety of your home.
Benefits:
- Reliable Draft: Achieve a dependable, steady draft that ensures your chimney operates at peak efficiency.
- Eliminate Smoke: Bid farewell to smoke-related woes, and enjoy a clean and safe living environment.
- Enhanced Safety: Reduce the risk of backdrafts, making your home safer for you and your loved ones.
- Energy Efficiency: Optimize your chimney's efficiency and reduce energy consumption.
- User-Friendly: Easy installation and operation, ensuring a hassle-free experience.
- Durability: Built to last, this chimney fan offers longevity and consistent performance.
- Peace of Mind: Enjoy your fireplace without the worry of draft or smoke issues.
Standard Equipment:
- 2"x4" or 4"x4" Junction Box with Cover and Conduit
- Fiber Mat and Mounting Brackets
- Bird Screen
- 5 Amp Fan Speed Control
Common Companion Product:
- Fan and Damper Control
- Mechanical Fireplace Damper
Features:
- Quiet Operation
- Variable-speed motor
- Use with gas-fired appliances
- Comes in 4 sizes
- Complete fan and control packages available from a single manufacturer
- Low operating costs
- 6-months Performance Guarantee
Specification
| Capacities | 0-1,800 CFM (0-3,000 m3/h) |
| Material | Cast Aluminum Housing and Stainless Steel Axial Vane |
| Drive | Axial Vane |
| Motor | Variable Speed, TEFC, Class H |
| Max. Temp | 575°F (300°C) |
| Warranty | 2-Year Factory Warranty 10-Year Warranty Against Corrosion Perforation |
| Listings | UL 378 Standard for Draft Equipment UL 705 Standard for Power Ventilators CSA3-B255-M81 Standard for Mechanical Flue Gas Exhauster |
| Model | RS 016 | ||
| Discharge | Horizontal | ||
| Fan Type | Axial Vane | ||
| Motor Type | Totally enclosed, Variable speed, Class H | ||
| Voltage | VAC | 1x120V @ 60 Hz | |
| Amperage | Amps | 3.9 | |
| RPM | 1600 | ||
| CFM | at 0.0Ps | 1950 | |
| Motor Output | hp / kW | 1/3 / 0.25 | |
| Weight | lbs / kg | 61 / 28 | |
| kg | 28 | ||
| Dimensions | A | in / mm | 16.0 / 407 |
| B x B | in / mm | 18.8 / 478 | |
| C | in / mm | 17.4 / 441 | |
| D | in / mm | 3.9 / 100 | |
| E | in | 15.4 / 391 | |
| Temperature Rating | Interm. | 575°F / 300°C | |
| Cont. | 482°F / 250°C | ||
Downloads:
About The Manufacturer:
ENERVEX provides a full line of listed, fully integrated commercial venting and mechanical draft control systems for a truly one-stop design from boiler outlet to chimney termination. ENERVEX products are economical, environmentally sustainable, aesthetically pleasing, reliable, and up to code for commercial projects around the globe.
