Description
Introducing the Kingsman MCVST42 Zero Clearance Direct Vent See-Through Gas Fireplace – an embodiment of refined luxury and cozy comfort. Designed to transform your living space into a haven of elegance, this fireplace is more than just a heat source; it's an artful centerpiece that ignites conversations and memories. Step into a realm of captivating ambience where flames dance gracefully, embracing both modern aesthetics and traditional charm.
Product Specification
| Model | MCVST42N/NE | MCVST42LP/LPE |
| Fuel | Natural | Propane |
| Flue | Top | Top |
| Gas Control | Millivolt / IPI | Millivolt / IPI |
| Input Max. | 30,250 BTU | 29,000 BTU |
| Input Min. | 20,750 BTU | 23,000 BTU |
| FE (p.4.1-02)% | 57.56% / 59.55% | 58.56% / 55.32% |
|
Flue Sizes |
5/8" | 5/8" |
|
Glass Size |
35 5/8" W x 29 9/32"H |
35 5/8" W x 29 9/32"H |
|
Glass Type |
Tempered | Tempered |
|
Size (WxHxD) |
43 1/16" W x 51 1/4"H x 24 1/4"D |
43 1/16" W x 51 1/4"H x 24 1/4"D |
|
Viewing Area |
33 11/16"W x 27 3/16"H |
33 11/16"W x 27 3/16"H |
|
Venting |
5/8" Flex or 5/8" Hard Pipe* or Power Vent |
5/8" Flex or 5/8" Hard Pipe* or Power Vent |
|
Electronic Ignition |
Yes | Yes |
| Certification | Decorative | Decorative |
|
Bedroom Approved |
Yes | Yes |
Standard Features
- Color: Black
- Vent Type: Direct Vent
- Dedicated Clean View appliance
- Fireplace Type: See-Thru Fireplace
- Fuel Type: Natural Gas, Propane Gas
- ANSI/CSA listed for both USA and Canada
- Specific Use Options: Mobile Home Approved / Bedroom Approved
- Able to be equipped with a full line of remotes and wall switches
- Low profile fireplace frame allows for a clean looking installation
- Includes safety barrier screens to prevent accidental contact with hot glass
- Able to utilize either a detailed 8 piece log set or contemporary glass media
- Double sided chassis is ideal for installation into both structural and partition walls
- Reliable standing pilot valve system ensures ready operation during power outages
- Intermittent pilot system eliminates the need for a standing pilot and offers reliable spark ignition
- Millivolt or IPI valve system allows operation during a power failure with Hi/Low heat and flame adjustment
*Venting Requirements: This unit requires venting pipe with an inner diameter of 5 Inches.
Downloads
About the Manufacturer:
Kingsman established its own distribution network in 1996, but the roots of the company go back much further than that. Company founder Russell Reyher made his first wood-burning gas stove in 1976 followed by an innovative line of gas fireplaces and freestanding stoves in 1983. Innovation is constantly at the forefront of Kingsman's operations with every aspect of every gas appliance in constant review for better performance, appearance, and value, and every product is fully certified for use in Canada and the United States. Located in the heart of North America, Kingsman prides itself on providing high quality at a fair price.
