Description
Included
- Fireplace Unit
- Literature Kit (Manuals & Guide)
- Two (2), 5 lb. bags, Reflective Black Glass Media
- 12 feet of two Conductor Wire
- Four (4), AA Batteries
- One (1), Fireboard Top
- One (1), Fireboard Bottom
- Two (2), Fireboard Sides
- 28 Self Drill Bugle Drywall Screws
- One (1) Heat Shield
- One (1) Pipe Shield
- Twelve (12) #10 Hex Head Screws
Optional Accessories
- See-Through Conversion Kit
- HeatFlo Kit and Extension
- Trim Kit
- Liner Kit
- Additional Glass Media
- River Rock
- Rock Media Kit
- Driftwood Log Set
- Remote Kit
- Blower Kit
- Touch Up Paint
- Gas Conversion Kit
Features
- Available in 48″, 60”, 72″ and 84″ linear configured models
- Indoor see-through conversion kit available to allow viewing from two living spaces
- Indoor/Outdoor see-through conversion kit available to enjoy the fire both inside and out (48” model only)
- HeatFlo™ kit option allows heat to be directed above heat sensitive wall hangings
- Electronic ignition with battery backup provides continued operation in the event of a power outage
- Clean-face design with integrated tile stops for easy finishing
- Ceramic glass for optimum heat transfer and a protective screen*
- Black painted interior standard with a reflective glass liner available
- Reflective black crushed glass media included with several optional colors available to customize the look
- Optional blower and hand-held multi-function remote control available**
- 20-year limited warranty
*All applicable models comply with ANSI Z21.88 barrier requirements.
**Blower use is not compatible with a see-through application.
Venting Notes
- Uses 4.5" / 7.5" Secure Vent Rigid and Secure Flex Direct-Vent Components
Specifications
| Model Number |
DRL4048 |
| Catalog Number |
F4846 |
| Fuel Type | Natural Gas Liquid Propane using Conversion Kit |
| Product Type |
Direct Vent Gas Fireplace |
| Framing Width |
55-5/8" |
| Framing Height |
39-1/8" |
| Framing Depth |
19-1/2" 18-1/2" (See Through) |
| BTU | 40,000-28,000 (NG) 31,000-25,500 (LP-field converted) |
| Design Style |
Contemporary |
| View Style |
Front-View |
| Controls | Remote Control |
| Agency Listing | Built to ANSI Z21.88-2019 and CSA 2.33 CAN/CGA 2.17 standards. PFS report F22-797 |
| AFUE* | 63.0% (NG) 63.0% (LP-field converted) |
| P4** | 62.5% (NG) 62.4% (LP-field converted) |
*AFUE is a measurement of the US Department of Energy
** P4 (EnerGuide) is a measurement of the Canadian Office of Energy Efficiency.
Product Dimensions

Warranty
![]() ttps://cdn.shopify.com/s/files/1/0686/3156/0499/files/20-Years-Warranty.jpg?v=1681616895 |
Innovative Hearth Products ("IHP") 20-Year Limited Warranty warrants your Superior® Brand gas fireplace, Stove, or Insert ("Product") to be free from defects in materials and workmanship at the time of manufacture. |
Documents & Files
- Product Brochure
- Smart Sheet
- Installation and Operation Manual
- Specifications Sheet
- See-Through Conversion Instructions
-
HeatFlo Kit Instructions Sheet
- HeatFlo Extension Kit Instructions Sheet
- HeatFlo Extension Kit Instructions Sheet (5in)
About The Manufacturer

Superior Fireplaces is dedicated to delivering best-in-class hearth products backed by exceptional customer service. Known for industry-leading quality, warmth, and innovative design, Superior offers a comprehensive selection of fireplaces, inserts, freestanding stoves, gas log sets, and chimneys to suit every style and budget. Their product lineup includes wood, gas, and electric solutions, along with a wide range of accessories designed to enhance comfort, performance, and style.
