SuperiorSKU: DRT63STTYN-B
Price:
$10,939.00

Description

The Superior DRT63ST 40 Inch Traditional Multi View See-Through Direct Vent Gas Fireplace with Power Vent combines the elegance of a see-through fireplace with the added flexibility of a dedicated power vent system. Designed for multi-view applications, this fireplace allows homeowners to enjoy a beautiful flame presentation from two adjoining spaces while creating a striking architectural focal point. The aged oak high-density fiber log set, heavy-duty grate, and smooth-face design provide a realistic and refined appearance, making it an excellent choice for both traditional and contemporary interiors.

Built for performance and convenience, the Superior DRT63ST Power Vent model features electronic ignition with battery backup for reliable operation during power outages. With up to 57,000 BTUs of heat output on natural gas and 50,000 BTUs on propane when converted, this fireplace delivers substantial warmth for larger living areas. Six adjustable flame settings with up to a 33% turn-down capability allow precise control of both heat and flame appearance, while the included full-function remote control makes it easy to adjust thermostat and flame settings from anywhere in the room.

Designed specifically with a dedicated power vent system, this fireplace offers enhanced venting flexibility for installations. Homeowners can further customize the fireplace with black reflective porcelain or ceramic fiber interior liners, while the optional outdoor window kit supports specialized installation applications. Backed by a 20-year limited warranty, the Superior DRT63ST Power Vent Fireplace delivers a premium combination of installation versatility, heating performance, and timeless see-through fireplace design.

Included

  • Fireplace Components:
    • (1) Literature Kit
    • (1) Remote Control Kit
    • (1) Log Set
    • (1) Vent Restrictor Assembly
    • (1) bag Platinum Glowing Embers
    • (4) bags Volcanic Stone
    • (1) ea. Door Modesty Shield
    • (2) Barriers
  • Power Vent Components:
    • (1) ea. Power Vent Termination
    • (1) ea. Termination Adaptor
    • (1) ea. Horizontal Firestop Assembly
    • (1) ea. Vacuum Hose
    • (1) ea. 11/32" Hose Clamp
    • (1) ea. Strain Relief
    • (1) ea. Bushing
    • (4) ea. 1/4" Insulated Male Terminals
    • (2) ea. #10 Ring Terminals

Required Accessories

  • Liner Kit
  • Power Vent Kit
  • Outdoor WindowKit

Optional Accessories

  • Volcanic Stone
  • Touch Up Paint
  • Glowing Embers
  • Gas Conversion Kit

Features

  • Available in a 40” See Through model. Configurable as indoor/indoor or indoor/outdoor applications
  • Gas controls are conveniently hidden to the side of the fireplace opening for easy installation and finishing
  • Electronic ignition with battery backup to provide continued operation in the event of a power outage
  • Six flame settings with up to a 33% turn-down for precise heat control
  • Smooth-face design features ceramic glass for optimum heat transfer and a protective screen*
  • Beautifully crafted aged oak high density fiber log set with heavy duty grate
  • Interior liner selections consists of two-piece black reflective porcelain or ceramic fiber
  • Full function remote control (T-stat, flame)
  • Dedicated power-vent (Natural Gas only)
  • Optional outdoor window kit, tested and listed to ASTM commercial window standard for air infiltration, water resistance, structural integrity and thermal resistance (U-Value/CRF)
  • 20 year Limited warranty

*All applicable models comply with ANSI Z21.50/88 barrier requirements.

Specifications

Brand
 Superior
Catalog Number
 F4693
Model Number
 DRT63STTYN-B
Fuel Type

Natural Gas

Liquid Propane using Gas Conversion Kit
Product Type
 Direct Vent Gas Fireplace
Framing Width
 52-1/16"
Framing Height 47-5/16"
Framing Depth
 26-5/16"
BTU 57,000 BTU (NG)
50,000 BTU (LP)
Design Style Traditional
View Style Multi-View
Controls Remote Control
AFUE** 65.1%
Energuide* 61.6%

*Intermittent ignition systems.
**Annual Fuel Utilization Efficiency (AFUE) is the recognized U.S. rating system for the total efficiency of heating products.

Product Specifications

E
 25-9/32"
F 13-3/32"
G 50-1/2"
H 12-5/16"
I 46-19/32"
J 34-3/4"
K 29-19/32"
L 33-3/4"
M 27-7/16"
N 7"

Warranty


ttps://cdn.shopify.com/s/files/1/0686/3156/0499/files/20-Years-Warranty.jpg?v=1681616895 		Innovative Hearth Products ("IHP") 20-Year Limited Warranty warrants your Superior® Brand gas fireplace, Stove, or Insert ("Product") to be free from defects in materials and workmanship at the time of manufacture.

Documents & Files

About The Manufacturer

Superior Fireplaces is dedicated to delivering best-in-class hearth products backed by exceptional customer service. Known for industry-leading quality, warmth, and innovative design, Superior offers a comprehensive selection of fireplaces, inserts, freestanding stoves, gas log sets, and chimneys to suit every style and budget. Their product lineup includes wood, gas, and electric solutions, along with a wide range of accessories designed to enhance comfort, performance, and style.
